Khoom Description
1. Substrate Hlau Chemical Composition:
| Qib | N | C | H | Fe | O | Ti |
| Qib 1 | 0.03 | 0.08 | 0.015 | 0.20 | 0.18 | bal |
2, Substrate Hlau Mechanical Properties:
| Qib | Tensile zog (min) | Yield zog (min) | Elongation (%) | ||
| ksi ua | MPa | ksi ua | Mpa | ||
| Gr1 | 35 | 240 | 25 | 170 | 24 |
Muaj ntau qhov laj thawj rau ruthenium iridium titanium anode passivation.
a. Txheej peeling
Lub titanium ruthenium iridium titanium anode yog tsim los ntawm titanium substrate thiab ruthenium iridium titanium active txheej. Cov tshuaj tiv thaiv electrochemical nkaus xwb yog ruthenium iridium titanium active txheej. Yog hais tias lub txheej tsis ruaj khov rau lub substrate
Khoom, cais tawm ntawm titanium phaj substrate, rau qee qhov, titanium ruthenium iridium titanium anode poob nws txoj haujlwm. (Pib rau hauv crushing hom detachment, convex plab hom delamination, thiab tawg hom detachment)
b. Kev sib cais ntawm RuO2
Qhov tshwm sim ntawm txo cov pa oxygen tuaj yeem ua rau qeeb ntawm kev tsim cov oxide zaj duab xis. Thaum tag nrho cov tam sim no ceev ntawm electrolysis nce, tus nqi ntawm cov tshuaj chlorine nce ntau ntau dua li tus nqi ntawm cov pa oxygen, yog li qhov nce ntawm qhov ceev tam sim no muaj txiaj ntsig zoo rau kev txo qis cov ntsiab lus oxygen hauv chlorine. Lub titanium substrate tau txais kev kho mob ua ntej oxidation, tsim ib txheej ntawm oxide zaj duab xis ua ntej, uas tuaj yeem ua rau kom muaj zog ntawm kev sib khi ntawm ruthenium iridium titanium active txheej thiab titanium substrate, ua rau cov txheej ruaj khov thiab tiv thaiv kev sib cais thiab kev sib cais ntawm ruthenium. Txawm li cas los xij, nws tuaj yeem ua rau muaj qhov nce hauv ohmic poob ntawm ruthenium iridium titanium anode.
c. Oxide saturation
Cov txheej txheej nquag yog tsim los ntawm cov tsis muaj stoichiometric RuO2- thiab TiO2, koom nrog pawg ntawm anoxic oxides. Qhov chaw ua kom muaj tseeb rau cov tshuaj chlorine tawm tsis yog stoichiometric oxides. Qhov ntau cov oxides muaj, cov chaw ua haujlwm ntau dua muaj, thiab qhov ua haujlwm zoo dua ntawm ruthenium iridium titanium anode. Lub conductivity ntawm ruthenium iridium titanium coated anodes yog tus cwj pwm los ntawm kev tsim ntawm distorted n-hom sib xyaw crystals los ntawm tib hom siv lead ua RuO2 thiab TiO2 tom qab kev kho cua sov, nrog qee qhov chaw ua haujlwm oxygen tam sim no. Thaum cov pa oxygen vacancies tau ntim nrog oxygen, qhov overpotential sai sai, ua rau passivation.
d. Cracks nyob rau hauv lub txheej
Thaum lub sij hawm electrolysis, ecological oxygen tshiab yog tsim nyob rau hauv lub ruthenium iridium titanium anode, nrog ib co ntawm nws tawm ntawm lub interface ntawm lub active txheej thiab electrolyte, thiab ces tawm hauv lub anode nto los tsim oxygen thiab nkag mus rau hauv cov tshuaj; Vim tias muaj cov kab nrib pleb hauv cov txheej txheem nquag, thaum lwm qhov ntawm cov pa oxygen adsorbs ntawm qhov chaw anode, nws kis tau los yog txav mus los ntawm cov txheej txheem kom ncav cuag qhov sib cuam tshuam ntawm txheej txheej thiab titanium phaj substrate. Tom qab ntawd, cov pa oxygen yog chemically adsorbed rau ntawm titanium substrate nto, ua ib zaj duab xis uas tsis yog-conductive oxide (TiO2) nrog titanium, generating reverse resistance; Xwb, cov electrolyte invades los ntawm cov kab nrib pleb nyob rau hauv lub txheej, ua rau lub titanium substrate maj mam oxidize thiab corrode nyob rau hauv lub interface nrog lub ruthenium iridium titanium active txheej, ua rau lub ruthenium iridium titanium active txheej rau detach thiab ua rau cov anode muaj peev xwm ntawm iridium ruthen. titanium. Qhov kev nce hauv qhov muaj peev xwm ntxiv txhawb kev tawg ntawm txheej thiab oxidation ntawm titanium substrate
Peb qhov zoo dua
Cov khoom zoo
Titanium anode factories tuaj yeem muab cov khoom lag luam zoo titanium anode nrog kev tiv thaiv corrosion zoo heev, hnav tsis kam, thiab kub tsis kam.
Diversified khoom qauv
Titanium anode factories tuaj yeem tsim ntau yam tshwj xeeb thiab qauv ntawm titanium anode cov khoom raws li qhov sib txawv ntawm cov neeg siv khoom kom tau raws li lawv cov kev xav tau ntau yam.
Cov txheej txheem ntau lawm
Lub Hoobkas titanium anode dav siv ntau lawm thiab kev siv tshuab los xyuas kom meej tias cov khoom tsim tau ruaj khov thiab ua haujlwm zoo.
Kev pabcuam zoo
Lub Hoobkas titanium anode muaj ib pab neeg ua haujlwm pabcuam uas tuaj yeem muab cov neeg siv khoom zoo thiab txhawb nqa 24/7 kom ntseeg tau tias cov neeg siv khoom tau txais kev paub zoo tshaj plaws.
Peb lub tuam txhab yog lub tuam txhab ntiag tug tshwj xeeb hauv kev tshawb fawb, kev tsim kho, tsim khoom thiab muag khoom ntawm txhua yam khoom sib xyaw thiab cov khoom siv titanium, Peb cov khoom: Ru-ir txheej titanium anode, platium txheej titanium anode, Ir-ta txheej titanium anode, titanium cathode. Peb pab neeg muaj ntau tshaj 10 xyoo kev paub, thiab dhau los ntawm kev txhim kho thiab kev qhia txog kev siv tshuab, peb cov khoom tau txais kev pom zoo thiab tau muab rau ntau lub teb chaws thoob ntiaj teb, xws li Asmeskas, Lub teb chaws Yelemees, Fabkis, Brazil, Spain, Nyiv, Kauslim, Indonesia, Nyab Laj, Malaysia, Pakistan, thiab lwm yam.
Ruthenium iridium tantalum coated titanium anodes muaj ntau yam zoo hauv electrochemical teb, xws li:
1. Muaj zog corrosion kuj: Ruthenium iridium tantalum coated titanium anodes muaj corrosion kuj zoo heev thiab yuav siv tau rau lub sij hawm ntev nyob rau hauv acidic thiab alkaline ib puag ncig tsis muaj corrosion, ua rau lawv haum rau ntau yam tshuaj tiv thaiv thiab dej phwj tuaj kho.
2. Kev ruaj ntseg siab: Lub ruthenium iridium tantalum coated titanium anode muaj kev ruaj ntseg thiab kub tsis kam, tuaj yeem tiv taus qhov kub thiab txias siab, thiab tsis deform lossis ablate rau kev siv mus ntev.
3. High electrocatalytic efficiency: Qhov saum npoo ntawm ruthenium iridium tantalum coated titanium anode yog du thiab muaj catalytic efficiency siab, ua kom cov tshuaj tiv thaiv electrochemical ceev thiab txhim kho cov tshuaj tiv thaiv, yog li txo cov tshuaj tiv thaiv lub sij hawm thiab lub zog noj, thiab txo cov nqi.
4. Lub neej ua haujlwm ntev: Vim muaj kev tiv thaiv zoo heev thiab kev ruaj ntseg ntawm ruthenium iridium tantalum coated titanium anodes, lawv muaj lub neej ua haujlwm ntev thiab tuaj yeem siv tau ntev hauv ntau qhov chaw, zam kev hloov pauv ntau zaus.
5. Kev nyab xeeb siab: Vim nws muaj peev xwm tiv taus qhov kub thiab txias siab, ruthenium iridium tantalum coated titanium anodes tsis tsim cov khoom phom sij thaum siv, yog li muaj kev nyab xeeb siab.
Hauv cov ntsiab lus, ruthenium iridium tantalum coated titanium anodes muaj ntau yam zoo, ua rau lawv siv dav hauv kev lag luam xws li electrochemistry, tshuaj tiv thaiv, thiab kev kho dej phwj tuaj, ua cov khoom tseem ceeb tshiab.
Piv txwv
Kev rho tawm electrolytic ntawm cov hlau hauv sulfuric acid daws, nag lossis daus ntawm oxygen ntawm anode, thiab xaiv cov khoom tsim nyog anode yog qhov teeb meem tseem ceeb heev. Lub titanium electrode coated nrog tantalum iridium series muaj cov pa oxygen tsawg dhau thiab tsis corroded los ntawm electrolyte. Lub iridium oxide txheej qhia tau zoo heev electrolytic durability. Thawj qhov peev xwm anode yog 1.51V, thiab tom qab 6000 teev, nws yog 1.64V. Qhov hnyav ntawm cov txheej yog 0mg / cm2.
Thaum siv cov hlau lead raws li cov electrodes (muaj 6 feem pua rau 15 feem pua Sb lossis 1 feem pua Ag) hauv cov khoom siv electrolytic, cov hlau lead anode yuav yaj, siv cov khoom siv anode thiab cuam tshuam rau anode lub neej kev pab cuam. Ntxiv mus, cov hmoov lead yaj nyob rau hauv cov tshuaj yuav precipitate ntawm lub cathode, ua rau cov hlau impurities nyob rau hauv cov hlau thiab txo cov khoom zoo.
Lub ruthenium raws li txheej yuav raug mob hnyav nyob rau hauv qhov kev ua haujlwm no, yog li nws tsis haum rau kev siv. Thawj qhov peev xwm anode yog 1.48V, thiab tom qab 1000 teev, nws tau nce mus rau 2.0V, qhia tias cov anode tau passivated.
Precious hlau coated titanium anodes muaj zoo heev electrocatalytic kev ua tau zoo thiab electrochemical kev ua tau zoo, thiab muaj ib tug tej yam kev pab cuam lub neej. Lawv tau siv dav hauv kev lag luam chlor alkali, kev lag luam high-speed electroplating, thiab lwm yam lag luam. Nyob rau hauv lub tshav pob ntawm non-ferrous hlau electrolysis, sawv cev los ntawm electrolytic zinc, precious hlau coated anodes kuj qhia txog cov yam ntxwv ntawm kev txuag hluav taws xob, efficiency, thiab kev tiv thaiv ib puag ncig. Nyob rau hauv xyoo tas los no, lawv tau txais kev txaus siab los ntawm cov kws tshawb fawb. Cov nram qab no yuav tsum tau tshawb nrhiav thiab kawm ntxiv:
1) Txhim kho cov txheej txheem txheej. Ib txwm tsis tshua muaj thiab muaj nuj nqis hlau txheej xws li RuO2 thiab IrO2 muaj cov nqi siab. Nyob rau hauv lub hauv paus ntawm tsis cuam tshuam rau conductivity thiab kev pab cuam lub neej, ntxiv ib co tsawg-nqi hlau cov ntaub ntawv los txo cov nqi raw khoom yuav ua tau zoo dua kev lag luam nce.
2) Kev txhim kho ntawm kev sib txuas lub zog ntawm cov txheej thiab cov substrate. Titanium anodes feem ntau yog npaj los ntawm thermal decomposition thiab electrochemical deposition txoj kev, nrog tsis tshua muaj zog bonding thiab yooj yim tev. Cov txheej txheem tshiab thiab cov txheej txheem yog nrhiav los txhim kho lub zog sib txuas ntawm cov txheej txheem thiab cov txheej txheem, hloov txoj kev sib txuas, thiab txuas ntxiv lub neej kev pabcuam.
3) Kev tshawb fawb ntxiv yog xav tau ntawm kev txhim kho corrosion tsis ua haujlwm nyob rau hauv multiphase thiab complex systems. Electrochemical corrosion, acidification corrosion, thiab oxidation corrosion coexist nyob rau hauv lub electrolysis system. Los ntawm kev tshawb nrhiav qhov kev siv zog corrosion thiab tsis ua haujlwm ntawm ntau hom kev xeb, lub hom phiaj kev txhim kho ntawm lub neej ntev anodes tuaj yeem ua tiav.
